VT-12T

CNC TORNA TEZGAHI

WORKING CAPACITY

Swing over Z-way covermm400
Max. turning diametermm180
Swing over cross slidemm120
Max. turning lengthmm150

TRAVELS

X-axis Travelmm217
Z-axis Travelmm220

SPINDLE

Type of Spindle NoseISOA2-6
Chuck Diameter and Typemm204/8
Through Spindle Hole Diametermm62
Spindle Bearing Inner Diametermm110
Through Bar Capacitymm52
Spindle Motor Powerkw/HP11
Spindle Speeddevir / dk5000

CONTROL UNIT

MITSUBISHIM80A
FANUC0İMATE-TD, 0İTD

TURRET

Number of tool stationsadet8
Turret typeSTATIC
Turret indexing timesaniye0,9

FEED RATE

X-axis cutting feedratemm / dk10000
Z-axis cutting feedratemm / dk10000

OTHER

Machine Weightkg2550
Machine Floor Spacemm2468x2213

STANDARD ACCESSORY

FOOT SWITCH FOR SPINDLE CLAMP/UNCLAMP

COOLANT SYSTEM

WORK LIGHT

AUTO LUBRICATION SYSTEM

TOOL BOX WITH HAND TOOL

OPERATION FINISH LAMP

FOUNDATION BOLTS

HEAT EXCHANGE FOR CONTROL SYSTEM

OPTIONAL ACCESSORIES

1 SET HARD JAW

SOFT JAWS (3 SET)

CHIP CONVEYOR

CHIP BUCKET

380V/50Hz TRANSFORMER

DOOR LOCK

FULL SPLASH GUARD

DIRECT DRAW PROGRAMMING

GRAPHIC SCREEN

TOOL MEASURING ARM
